| CPU Socket | LGA1700 |
| CPU | Intel® Core™ 200E / 200PE & 14th/13th/12th Core i LGA1700 Processors |
| PCH | Q670E, R680E |
| Memory | 4x DDR5 U-DIMM sockets, Max. 192GB |
| BIOS | AMI |
| Watchdog Timer | 256 levels |
| H/W Monitor | Yes |
| Storage Device Interface | SATA III & NVMe |
| Expansion Slots | 2x PCIe (x16) [Gen.5.0]; 2x PCIe (x4) [Gen.4.0] ; 2x PCIe (x1) [Gen.3.0] |
| Mini Type Slots | 2x M.2 (M2280, supports NVMe (Gen4)1x M.2 (E2230, supports CNVi)1x M.2 (B3052, supports 5G module) |
| Graphics Controller | 12th Gen Intel® Core™ i9/i7/i5/i3 processors integrated |
| Video Output | 2x DisplayPort /DP++ (1.4a)1x HDMI (2.0)1x DVI-D |
| Ethernet | LAN 1: Intel® I226LM, supports iAMTLAN 2: Intel® I226V, supports 2.5G only |
| I/O Chip | Fintek F81964D-I |
| Serial Port | 4x COM ports: 2x RS232/422/485 + 2x RS232 |
| USB 2.0 | 2x USB 2.0 via pin-header |
| USB 3.X | 4x USB 3.2(10 Gbps) @ rear panel2x USB 3.1 Gen1(5 Gbps) support Type-A @ rear panel2x USB 3.2 @ onboard box headers1x USB 3.2 @ onboard vertical connector |
| Serial ATA | 4x SATA III |
| Audio | Built-in HD Audio controller + Realtek ALC888S-VD2-GR w/ 7.1 channels |
| TPM | TPM(2.0) |
| Others | Digital I/O (4-in/4-out), iSMART (4.0), iAMT (16.1), dTPM (2.0), RAID |
| Dimensions (L x W) | 305mm x 244mm (12"x 9.6") |
| Power Consumption | TBD |
| Operating Temperature | 0°C~60°C ( 32°F~140°F) |
| Storage Temperature | -20°C~80°C (-4°F~176°F) |
| Relative Humidity | 90% (non-condensing @60°C) |
