MI963

AMD Embedded G-Series SoC Mini-ITX Motherboard w/ GX-424CC SoC 2.4 GHz

AMD Embedded G-Series SoC Mini-ITX Motherboard w/ GX-424CC SoC 2.4 GHz. Supplied across Canada and the United States by IBT Technologies, with local warranty support and engineering customization available on request.

CPU

AMD Embedded G-Series GX-424CC SoC (2.4GHz)

MEMORY

2x DDR3 DIMM, Max. 8GB (ECC compatible )

STORAGE

N/A

DISPLAY

Supports 2x HDMI

Legacy catalogueIBASE Technology

REQUEST QUOTE REQUEST DATASHEET

MFR. PART # MI963 — IBASE Technology

Specifications

22 ROWS

CPU	AMD Embedded G-Series GX-424CC SoC (2.4GHz)
System Memory	2x DDR3 DIMM, Max. 8GB (ECC compatible )
System Chipset	Integrated
BIOS	AMI
Watchdog Timer	256 levels
SSD	N/A
H/W Monitor	Yes
Expansion Slots	1x PCI-E(x8)[(x4) Link]
VGA Controller	AMD Embedded G-series SoC built-in GPU · (AMD Radeon™ HD8000 series)
Display Interface	Supports 2x HDMI
LAN Controller	2x Intel® I211AT PCI-E Gigabit LAN
LAN Connector	2x RJ-45 on board
I/O Chipset	Fintek F81846AD-I · 3x RS232, 1x RS232/422/485 (jumperless selection) · 2x SATA III
USB	4 ports onboard, 2 ports via pin-header (USB 2.0) · 2 ports onboard (USB 3.0)
Audio	AMD Embedded G-series SoC built-in audio controller w/ Realtek ALC662QHD codec · Extra 3W + 3W amplifier
Others	Digital I/O (4-in/4-out), ATX power connector
Dimensions	170mm x 170mm (6.7“ x 6.7“)
Max. Power Requirement	AMD GX-424CC 2.4GHz · w/ 2x DDR3L-1600 8G
+12V	1.56A; +5V: 1.75A; +5VSB: 0.13A; +3.3V: 0.23A
Operating Temperature	0°C~60°C (32°F~140°F)
Storage Temperature	-20°C~80°C (-4°F~176°F)
Relative Humidity	90% (non-condensing @60°C)

Features

7 ROWS

Feature 1	Onboard AMD Embedded G-Series GX-424CC SoC, 2.4GHz
Feature 2	2x DDR3 DIMM, Max. 8GB
Feature 3	Supports 2x HDMI
Feature 4	2x Intel® PCI-E Gigabit LAN
Feature 5	Watchdog timer, Digital I/O
Feature 6	6x USB 2.0, 2x USB 3.0, 6x COM
Feature 7	2x SATA III, 1x PCI-E(x8) [(x4) Link]

Ordering Information

2 ROWS

MI963F-222	- AMD Embedded G-series GX-222GC APU on board Mini-ITX motherboard, w/ 2x HDMI, PCI-E, dual Gigabit LAN
MI963F-424	- AMD Embedded G-series GX-424CC APU on board Mini-ITX motherboard, w/ 2x HDMI, PCI-E, dual Gigabit LAN
