MI979

Carte mère — MI979 - AMD Embedded R-Series /G-Series APU Mini-ITX AMD RX-421BD

Carte mère — MI979 - AMD Embedded R-Series /G-Series APU Mini-ITX AMD RX-421BD. Distribué au Canada et aux États-Unis par IBT Technologies, avec soutien de garantie local et personnalisation d’ingénierie offerte sur demande.

CPU

AMD R/G-series APU on board, up to 3.4GHz

MEMORY

2x DDR4 SO-DIMM Max. 32GB, supports ECC (R-series) · 1x DDR4 SO-DIMM Max. 16GB, (G-series)

STORAGE

1x mSATA (via Mini PCI-E)

DISPLAY

HDMI, DisplayPort and 24-bit dual channel LVDS or eDP

Legacy catalogueIBASE Technology

DEMANDER UNE SOUMISSION DEMANDER LA FICHE TECHNIQUE

N° DE PIÈCE FABRICANT MI979 — IBASE Technology

Specifications

22 LIGNES

CPU	AMD R/G-series APU on board, up to 3.4GHz
System Memory	2x DDR4 SO-DIMM Max. 32GB, supports ECC (R-series) · 1x DDR4 SO-DIMM Max. 16GB, (G-series)
System Chipset	N/A
BIOS	AMI
Watchdog Timer	256 levels
SSD	1x mSATA (via Mini PCI-E)
H/W Monitor	Yes
Expansion Slots	1x PCI-E (x8), 1x Mini PCI-E,1x M.2
VGA Controller	AMD R/G-series APU built-in Radeon HD9000 series · graphics core
VGA Memory	Shared memory
Display Interface	HDMI, DisplayPort and 24-bit dual channel LVDS or eDP
LAN Controller	2x Intel I211-AT Gigabit LAN
LAN Connector	RJ-45 on board
I/O Chipset	Nuvoton NCT6116D · 1x RS232/422/485( jumperless selection) · 5x RS232, 2x SATA III (6.0Gb/sec.)
USB	2 ports (USB 3.0) + 2 ports (USB 2.0) on board · 2 ports via pin header (USB 2.0)
Audio	Built-in HD audio w/ ALC662 codec for 5.1 channel
Others	Digital I/O (4-in/4-out), iSMART, SIM card slot
Dimensions	170mm x 170mm (6.7“ x 6.7“)
Max. Power Requirement	TBD
Operating Temperature	0°C~60°C (32°F~140°F)
Storage Temperature	-20°C~80°C (-4°F~176°F)
Relative Humidity	90% (non-condensing @60°C)

Features

8 LIGNES

Feature 1	Supports AMD R/G-series APU on board, up to 3.4GHz
Feature 2	2x DDR4 SO-DIMM, Max. 32GB support ECC
Feature 3	2x PCI-E Gigabit LAN
Feature 4	1x HDMI, 1x DisplayPort and 24-bit dual channel LVDS or eDP
Feature 5	Watchdog timer, Digital I/O, iSMART
Feature 6	2x SATA III, 2x USB 3.0, 4x USB 2.0, 6x COM, 1x mSATA
Feature 7	1x PCI-E(x8), 1x Mini PCI-E, 1x M.2 (B-key)
Feature 8	1x SIM card slot

Ordering Information

3 LIGNES

MI979MF-421	- AMD RX-421BD APU on board (2.1GHz/3.4GHz) Mini-ITX motherboard w/ HDMI + DP and LVDS or eDP, dual Gigabit LAN, iSMART, ATX
MI979MF-421D	- AMD RX-421BD APU on board (2.1GHz/3.4GHz) Mini-ITX motherboard w/ HDMI + DP and LVDS or eDP, dual Gigabit LAN, iSMART, DC-in (12V~24V)
MI979BF-217	- AMD GX-217GI APU on board (1.7GHz/2.0GHz) Mini-ITX motherboard w/ HDMI + DP, dual Gigabit LAN, iSMART, ATX
