All-In-One Panel PC of 18.1 inch Freeescale ARM Based
All-In-One Panel PC of 18.1 inch Freeescale ARM Based. Supplied across Canada and the United States by IBT Technologies, with local warranty support and engineering customization available on request.
| Processor | Freescale I.MX6 Cortex A9 Solo 1 Cores @ 1GHz |
| System Memory | 1GB DDR3 memory board |
| USB | 1x USB (USB Host. A-Type) (Flag type) · 1x USB OTG (mini AB type) |
| Serial/Parallel | 1x RS-232/485 via RJ-45 connector (selectable by dip switch at edge, Default RS-232) |
| Audio | None |
| Display Interface | None |
| LAN | 1x GbE LAN RJ-45 (Onboard) |
| Digital I/O | None |
| Keyboard/Mouse | None |
| Membrane Control | None |
| Power | 1x 3.5mm power jack · 1x Power reset button Switch |
| HDD | 4GB eMMC Onboard |
| Removable Slot | 1x SD card slot up to 32GB |
| Onboard Expansion Bus | 1x Mini PCI-E slot (Full size/half size) |
| Expansion Slot | None |
| Display Type | 18.5" TFT-LCD |
| Max. Resolution | 1366 x 768 |
| Max. Color | 16.7M |
| Luminance (cd/m2) | 300 |
| View Angle (H/V) | 170/160 |
| Contrast | 1000:1 |
| Backlight Lifetime(hrs) | 50000 |
| Touch Type | Projected capacitive touch |
| Interface | USB |
| Light Transmission (%) | 85 |
| Power Input | 12V DC input |
| Construction | Black aluminum front bezel and black steel back cover |
| IP Rating | IP65 (Front panel with panel mount) |
| Mounting | VESA 75x75/100x100 mm |
| Dimensions (mm) | 520 x 341 x 69.3 |
| Net Weight (kgs) | TBD |
| Operating Temperature(°C) | 0°C~ 50°C |
| Storage Temperature(°C) | -20°C~60°C |
| Storage Humidity | 10%~90% (non-condensing) |
| Certification | CE/FCC Class B |
| Operating System Support | Linux3.X, Android 4.X |
| Feature 1 | Freescale iMX.6 high performance processor |
| Feature 2 | Projected capacitive touch screen, flat bezel design |
| Feature 3 | Programmable LED light bar at rear side |
| Feature 4 | External SD card slot for storage expansion |
| Feature 5 | Android 4.3x supported |
| BYARM-181-PC | - RISC 18.5” Panel PC with projected capacitive touch, I.MX6 Cortex A9 CPU, 1GB DDR3 onboard, supports Android, w/ 60W power adaptor |
