| Display Size | 21.5” TFT-LCD |
| Max. Resolution | 1920 x 1080 |
| Luminance (cd/m2) | Up to 1200nits, default @75% |
| Contrast | 1000:1 |
| Max. Color | 16.7M |
| View Angle (H/V) | 140/120 |
| Backlight Lifetime(hrs) | 50000 |
| Touch Type | IR touch |
| Touch Interface | USB |
| Light Transmission (%) | 88 |
| Point of touch | Multi-Touch |
| USB 3.0/ 3.1 | 3x USB 3.1 (Type-A)1x USB (Type-C) |
| USB 2.0 | N/A |
| RS-232/422/485 Selectable in BIOS | 1 |
| RS-232 | 0 |
| LAN | 3x 2.5G GbE |
| Additional Graphics | DP + Type-C (Alternate Mode) |
| Audio | None |
| Digital I/O | None |
| Power Connector | AC inlet |
| Power Button | None |
| Dimensions (mm) | 574 x 357 x 82.5 |
| Net Weight (kgs) | 7.5 |
| Processor | Intel® Atom® x6413E Processor1.5M Cache, up to 3.00 GHz |
| Memory | 2x DDR4-3200 SO-DIMM,Max. 32GB |
| Thermal Design | Fan |
| Membrane Control | None |
| Built-in Speaker/MIC | None |
| Internal Expansion Bus | 1x M.2 (E-Key, type:2230)1x Mini PCI-E / mSATA |
| Expansion Slot | None |
| Wireless | optional Wi-Fi/BT |
| Storage | 1x 2.5” SATA |
| Power Input Range | 90V ~ 240V AC |
| Chassis Material | Aluminum front bezel, blackBlack SGCC + Aluminum chassis |
| Color (Front/Back) | Black/Black |
| IP Rating | IP65 front-panel waterproof protection |
| Mounting | open-frame rack mountingVESA 200x200 and 200x100 mm |
| Operating Temperature | Low Temperature: -40°C with installed heater insideHigh Temperature: with 1120 W/m2solar energy: 44 °C |
| Storage Temperature | -20°C~60°C |
| Storage Humidity | 5%~90% @ 50°C, (non-condensing) |
| Certification | CE/FCC Class-B |
| Supported Operating Systems | Windows 10 / Linux Ubuntu |
