PC À ÉCRAN TACTILE / EN STOCK

IPPC 121

PC à écran tactile sans ventilateur — Intel® Atom® x7000E Series / N-series / Core™ 3 N355 Processors (formerly Alder Lake-N / Amston Lake / Twin Lake) USB Type-C PD60W

PC à écran tactile sans ventilateur — Intel® Atom® x7000E Series / N-series / Core™ 3 N355 Processors (formerly Alder Lake-N / Amston Lake / Twin Lake) USB Type-C PD60W. Distribué au Canada et aux États-Unis par IBT Technologies, revendeur autorisé IBASE, avec soutien de garantie local et personnalisation d’ingénierie offerte sur demande.

CPU

Intel® Atom™ N97 Processor (4 Cores) up to 3.6GIntel® Atom™ N150 Processor (4 Cores) up to 3.6GIntel® Core™ i3 N305 Processor (8 Cores) up to 3.8GIntel® Core™ 3 N355 Processor (8 Cores) up to 3.9GIntel® Atom™ X7835RE Processor (8 Cores) up to 3.6G

MEMORY

1x DDR5 SO-DIMM, up to 16GB

STORAGE

N/A

DISPLAY

12.1”

IPPC Series Compact Panel PCIndustrial Panel PC

DEMANDER UNE SOUMISSION FICHE TECHNIQUE (PDF)

N° DE PIÈCE FABRICANT IPPC_121 — IBASE Technology · VOIR LA PAGE DU FABRICANT ↗

Specifications

42 LIGNES

Display Size	12.1”
Max. Resolution	1024 x 768
Luminance (cd/m2)	500
Contrast	1000:1
Max. Color	16.7M
View Angle (H/V)	178/178
Backlight Lifetime(hrs)	30,000
Touch Type	Projected capacitive
Touch Interface	USB
Light Transmission (%)	85
Point of touch	Up to 10
USB 3.0/ 3.1	2x USB 3.21x USB Type-C (Alternate mode w/ PD 60W)
USB 2.0	4
RS-232/422/485 Selectable in BIOS	COM 1
RS-232	COM2 and optional 3~6
LAN	2x GbE
Additional Graphics	HDMI1x USB-C (DP Alternate mode)
Audio	Combo Jack
Digital I/O	4x DI and 4x DO
Power Connector	2-pin bare-wire DC-in & GND screw
Power Button	Tact Switch
Dimensions (mm)	303.4 x 242 x 72.9
Net Weight (kgs)	3.6
Processor	Intel® Atom™ N97 Processor (4 Cores) up to 3.6GIntel® Atom™ N150 Processor (4 Cores) up to 3.6GIntel® Core™ i3 N305 Processor (8 Cores) up to 3.8GIntel® Core™ 3 N355 Processor (8 Cores) up to 3.9GIntel® Atom™ X7835RE Processor (8 Cores) up to 3.6G
Memory	1x DDR5 SO-DIMM, up to 16GB
Thermal Design	Fanless
Membrane Control	None
Built-in Speaker/MIC	None
Internal Expansion Bus	1x M.2 2280 (M-key + B-key)1x M.2 2230 (E-key)1x M.2 3043 (B-key)
Expansion Slot	N/A
Wireless	Optional Wi-Fi/BT/4G/5G/LTE
Storage	N/A
Power Input Range	DC +9V~36V
Chassis Material	Aluminum and SGCC
Color (Front/Back)	Gray / Black
IP Rating	IP66 front-panel waterproof protection
Mounting	VESA 75x75 and 100x100 mm, PanelMount and optional side mount
Operating Temperature	N97, N305 and N305: -20°C~50°C (-4°F~122°F)N150: -20°C~70°C (-4°F~158°F) with airflowx7835RE: -30°C~60°C (-22°F~140°F) with airflow
Storage Temperature	-30~80°C (-22°F~176°F)
Storage Humidity	10%~90% (non-condensing)
Certification	CE/FCC Class-B and LVD
Supported Operating Systems	Windows 10, 11 / Linux Kernel 4+
