| System Mainboard | MBN8505 |
| CPU Type | Intel® Xeon® D-2700 Processor |
| System Speed | up to 3.50 GHz |
| Memory | 4x DDR4 DIMMs, Max. 256GB RDIMM or 512GB LRDIMM, up to 3200MHz |
| AI Inference Computing Power | NVIDIA L4 Tensor card |
| Front Panel External I/O | 1x LED, 1x Power switch, 1x MGMT, 1x RJ45 console, 1x VGA, 1x RS422, 2x USB3.0, 2x PCI-E expansion slot, 2x 2.5” Hot Swappable SATA/NVMe SSD, 4x 25GbE SFP28 |
| Rear Panel External I/O | 1x AC Intel (2 AC 100~240V)1x Swappable system fan (1+4 hot-swappable 40x40x28 mm fans) |
| Expansion Slot | 1x PCI-E x16 Expansion slot (optional by SKU)1x PCI-E x8 Expansion slot (optional by SKU) |
| Storage | 1x 16GB/32GB/64GB eMMC2x M.2 (M-Key); supports SATA & PCI-E2x 2.5” SATA/ NVMe/ hot-swappable HDD/SSD |
| Power Requirement | 1+1 AC 100~240V @ 50~60 Hz full range 550W CRPS Redundant Power |
| Power Supply | Full-range 550W CRPS 1+1 redundant power supply |
| Construction | Aluminum & steel |
| Chassis Color | Black |
| Mounting | N/A |
| Weight | 15 kg (33.06 lbs) (estimated) |
| Dimensions | 438(W) x 420(D) x 43.8(H) mm17.24” (W) x16.54” (D) x 1.72” (H) |
| Operating Temperature | 0°C ~ 50°C (32°F ~ 104°F) |
| Storage Temperature | -20°C ~ 70°C (-4°F ~ 158°F) |
| Relative Humidity | 5% ~ 90% |
| Vibration | Operating: 0.25 Grms (3~500Hz) Z-axis, duration 60 minsNon-operating: 1.0 Grms (3~500Hz) Z-axis, duration 60 mins |
| Shock | Operating :20G/11 ms, Z/Y/Z axis, each axis 3 timesNon-operating: 40G/ 11ms, Z/Y/Z axis, each axis 3 times |
| Certification | CE/FCC |
| Operating System | Windows 11, Linux (6.5/ 11/ 22.04) |
