IBBOXN3350

Système IB-BOX-N3350 , Ultra small Embedded sans ventilateur — Intel Apollo Lake N3350 Dual Core

Système IB-BOX-N3350 , Ultra small Embedded sans ventilateur — Intel Apollo Lake N3350 Dual Core. Distribué au Canada et aux États-Unis par IBT Technologies, avec soutien de garantie local et personnalisation d’ingénierie offerte sur demande.

CPU

Intel Apollo Lake processor N3350

MEMORY

DDR3L-1600/1866 MHz, 1 x SO-DIMM, up to 8GB

STORAGE

1 x SATA 3.0

DISPLAY

1 x VGA (Up to 1920 x 1200 @ 60Hz),1 x HDMI (Up to 3840 x 2160 @ 60Hz),1 x LVDS (Up to 1920 x 1200 @ 60Hz)

Legacy catalogueIBT Technologies

DEMANDER UNE SOUMISSION DEMANDER LA FICHE TECHNIQUE

N° DE PIÈCE FABRICANT IBBOXN3350 — IBT Technologies

Specifications

28 LIGNES

CPU	Intel Apollo Lake processor N3350
Chipset	Intel SoC integrated
System Memory	DDR3L-1600/1866 MHz, 1 x SO-DIMM, up to 8GB
BIOS	AMI
COM	2 x RS-232
USB	2 x USB 3.0, 6 x USB 2.0
Ethernet	2 x RJ-45, Realtek RTL8111H Giga LAN
PoE	No
Display	1 x VGA (Up to 1920 x 1200 @ 60Hz),1 x HDMI (Up to 3840 x 2160 @ 60Hz),1 x LVDS (Up to 1920 x 1200 @ 60Hz)
Digital I/O	4 x Input / 4 x Output programmable
Audio	Realtek 5.1 channel HDA Codec, with MIC/Line-out (Internal connector)
Storage	1 x SATA 3.0
Expansion	2 x Mini-PCIe (1 x mSATA, 1 x Wifi/3G/4G supported)
Others	1 x 8-bit GPIO, 1 x I2C, 1 x SMBUS 1 x Speaker header 1 x DC 9 - 36V 4-pin ATX Power Input Connector
Power Supply	1 x DC 9-36V power input connector with lock
Optional	Phoenix contact connector
Watchdog Timer	1 - 255 steps by software program
Construction	-
Dimensions	182 x 115 x 55 mm
Weight	1.1 kg
Certifications	CE, FCC
EOS Support	-
Software Support	Win7, Win8, Win10 IoT, Linux
Mounting	VESA mount, DIN Rail with DIN Rail bracket (Optional), Wall Mount with Wall Mount bracket (Optional)
Operating Temperature	0°C to +60°C
Relative Humidity	10% to 95% relative humidity, non-condensing
Vibration	-
Shock	-

Features

5 LIGNES

Feature 1	Intel Apollo Lake N3350
Feature 2	DiskSize 3.5 inch small Computer
Feature 3	Mount Din-Rail or Wallmount
Feature 4	Dual Lan, Dual Serial, Dual video output, 6xUSB
Feature 5	Power Supply source 9~36VDC input

Ordering Information

4 LIGNES

IB-BOX-n3350	- Fanless Small 3.5 inch Computer, Dual Lan, Dual Serial, VGA / HDMI, 6xUSB, 9-36VDC power input
IB-BOX-WMRAIL	- WallMount bracket
IB-BOX-DM	- Din-Rail braket
Specify	- Memory and Storage requirement
