| CPU Socket | BGA1440 |
| CPU | AMD Ryzen™ Embedded R2000 series APU onboard |
| PCH | N/A |
| Memory | 2x DDR4-2666/2400 SO-DIMM socket, Max. 32GB, ECC compatible |
| BIOS | AMI |
| Watchdog Timer | 256 levels |
| H/W Monitor | Yes |
| Storage Device Interface | M.2 (M-key) |
| Expansion Slots | 1x PCI-E (x8) [R2514 & R2314] or 1x PCI-E(x4) [R2312] |
| Mini Type Slots | 1x M.2 (M-key, type:2280, SATA + PCI-E)1x M.2 (E-Key, type:2230, USB 2.0 + PCI-E)1x M.2 (B-Key, type:3052, USB 3.1 + PCI-E + SMBus) [R2514 & R2314] |
| Graphics Controller | AMD Radeon™ Graphics |
| Video Output | 2x HDMI + 2x DP (R2514 & R2314)2x HDMI + DP (R2312) |
| Ethernet | LAN 1: Intel® I226VLAN 2: Intel® I226V (R2514 & R2314) |
| I/O Chip | Nuvoton NCT6116D |
| Serial Port | 4 COM ports: 2x RS232/422/485, 2x RS232 |
| USB 2.0 | 2x USB 2.0 via pin header |
| USB 3.X | 2x USB 3.2 (10Gbps)@ edge connector; 2x USB 3.1 (5Gbps) via onboard box-header1x USB 3.1 (5Gbps) via onboard connector (R2514 & R2314) |
| Serial ATA | 1x SATA III |
| Audio | Built-in HD Audio controller + Realtek ALC888S w/ 5.1 channels |
| TPM | 2.0 |
| Others | Digital I/O (4-in/4-out) , Watchdog timer, SIM |
| Dimensions (L x W) | 170mm x 170mm (6.7“ x 6.7“) |
| Power Consumption | AMD Ryzen™ Embedded R2514 3.35GHz / R2314 2.1GHz / R2312 2.1GHz w/ 1x 8GB DDR4-2666+12V: ~2.9A+12V: ~2.2A+12V: ~1.9A |
| Operating Temperature | 0°C~ 60°C (32°F~140°F) |
| Storage Temperature | -20°C ~ 80°C (-4°F ~ 176°F) |
| Relative Humidity | 90% (non-condensing @60°C) |
