| Form Factor | Disk-Size SBC |
| CPU | NXP Cortex™-A9 i.MX6 Solo 1GHz |
| System Memory | 1GB DDR3 on board |
| Data Memory | 4GB eMMC on board · SD socket (up to 64GB) |
| Display | 18/24 bit single channel LVDS (up to 1366 x 768) |
| Video Codec | Decode: 1080p, 30fps Encode: 1080p, 30fps |
| LAN | 1st LAN 10/100/1000 Base-T Ethernet (Gb LAN) |
| Touch | PM6000 resistive touch IC (4/5-wires) on board USB/ I2C header on board (for capciative touch) |
| Audio | Audio pin header (1x microphone, 1x speaker) |
| RTC | Seiko RTC IC on board |
| Watchdog | 256 Levels |
| Edge I/O | 1x USB 2.0 Host (Type-A) · 1x USB OTG (mini-USB Type-B) · 1x COM (RS232/422/485) · 1x DC-in jack · 1x Reset button |
| Headers and Expansion Slots | Headers: · 8x GPIO pin header · 1x Debug port pin header · 1x USB2.0 host box header · 1x I²C pin header · 1x 4/5-wire resistive touch pin header · 1x Single channel LVDS box header (up to 1366 x 768) · 1x Audio pin header (1x microphone, 1x speaker) |
| Slots | 1x Full-size Mini PCI-E with USB interface |
| Others | 1x LED light bar (Green/Red/Orange configurable) |
| Power | 12V DC-in or PoE (IEEE 802.at Class3) |
| Dimensions | 131mm x 160mm (5.16” x 6.3”) |
| Devices | WiFi / GPS / 3G module (option) |
| Software Support | Ubuntu Linux 11.10(kernel 3.0.35)/ Android 4.3 |
| Certification | CE/FCC Class A |
| Operating Temperature | 0°C~ 60°C (32°F ~ 140°F) |
| Relative Humidity | 10%~90% (non-condensing) |
