ORDINATEURS MONOCARTES / EN STOCK

IB837

Ordinateur monocarte 3,5 po — Intel® Celeron® N & J Series SoC

Ordinateur monocarte 3,5 po — Intel® Celeron® N & J Series SoC. Distribué au Canada et aux États-Unis par IBT Technologies, revendeur autorisé IBASE, avec soutien de garantie local et personnalisation d’ingénierie offerte sur demande.

CPU

Intel® Celeron® QC J6412 (2.0GHz/2.6GHz)Intel® Celeron® DC N6210 (1.2GHz/2.6GHz)

MEMORY

1x DDR4-3200 SO-DIMM, Max. 16GB

STORAGE

1x mSATA1x M.2 B3042

DISPLAY

1x DisplayPort, 2x 24-bit dual-channel LVDS

x86 based 3.5 Single Board…Single Board Computer

DEMANDER UNE SOUMISSION FICHE TECHNIQUE (PDF)

N° DE PIÈCE FABRICANT IB837 — IBASE Technology · VOIR LA PAGE DU FABRICANT ↗

Specifications

24 LIGNES

CPU	Intel® Celeron® QC J6412 (2.0GHz/2.6GHz)Intel® Celeron® DC N6210 (1.2GHz/2.6GHz)
PCH	N/A
Memory	1x DDR4-3200 SO-DIMM, Max. 16GB
BIOS	AMI
Watchdog Timer	256 levels
H/W Monitor	Yes
Storage Device Interface	1x mSATA1x M.2 B3042
Mini Type Slots	Mini PCIe [for PCIe (x1) + USB 2.0 +SATA ]1x M.2 (B-Key, type:3042, SATA)1x M.2 (E-Key, type:2230, PCIe x1 + USB 2.0)
Graphics Controller	Intel® SoC integrated Gen11 Graphics
Video Output	1x DisplayPort, 2x 24-bit dual-channel LVDS
Ethernet	2x Intel® I226V PCI-E Gigabit LAN
I/O Chipset	Fintek F81966D-I
Serial Port	1x RS232/422/485 (Jumperless selection) & 5x RS232
USB 2.0	2x USB 2.0 (Pin-header)
USB 3.X	4x USB 3.1 (Type A)
Serial ATA	1x SATA III (shared with M.2 B-key)
Audio	Built-in HD with Realtek ALC888S + amplifier
TPM	fTPM
Others	Digital I/O (4-in/4-out), +12V DC-in
Dimensions (L x W)	102mm x 147mm (4" x 5.8")
Power Consumption	Intel® Celeron® J6412 2.00GHz w/ 8GB DDR4-3200 +12V:1.57A
Operating Temperature	0°C~60°C (32°F ~140°F)
Storage Temperature	-20°C~80°C (-4°F ~176°F)
Relative Humidity	95% (non-condensing @60°C)
