| System Mainboard | MBD623 |
| CPU Type | 7th/6th Generation Intel® Core™ mobile processor · TDP <=35W |
| CPU Socket | FCBGA 23 mm x 23 mm x 0.5 mm |
| Chipset | HM170/ QM170 PCH |
| Memory | 2x DDR4-2133 SO-DIMM, Dual channel, Max. 32GB |
| Graphics | Integrated Intel® HD Graphics 530 |
| LAN | 1x Gigabit LAN |
| Expansion Slots | 1x M.2 B key(3042) for storage, Wi-Fi, Bluetooth, 4G options · 1x M.2 M-Key (2280) for storage · 1x Mini PCI-E (full-size) for Wi-Fi, Bluetooth, 4G, or TV tuner options · 1x SIM card slot |
| I/O Interface | 1x HDMI 2.0 + 2x HDMI 1.4 with hardware EDID emulation · 2x USB 3.0 · 2x USB 2.0 · 1x RJ45 for Gigabit LAN · 1x RJ45 for RS-232 serial port · 2x Audio connectors for Mic in / Line out · Power / HDD LED, 1x power button · 1x power jack connector |
| Auto Control and Monitoring | Watchdog Timer: 256 segments, 0, 1, 2...255 (sec/min) |
| Power Requirement | +12V DC |
| Construction | Aluminum + SGCC |
| Weight | 2.4 kgs (5.29lbs) |
| Chassis Color | Black and white |
| Storage | 1x 2.5” SATA HDD/SSD |
| Power Supply | 84W power adaptor |
| Mounting | Slim design with wall mounting holes |
| Dimensions | 215.6mm(W) x 215.6mm(D) x 35mm(H) · 8.49”(W) x 8.49”(D) x 1.57”(H) |
| Operating Temperature | 0°C~ 45°C (32°F~113°F) |
| Storage Temperature | -20°C ~ 80°C (-4°F~176°F) |
| Relative Humidity | 5%~90% @45°C (non-condensing) |
| Vibration | SSD: 5 grms / 5~500Hz / random operation |
| Certification | CE, FCC class B, cULus and CCC |
| Operating System Support | Win7 32/64-bit, Win8.1 64-bit and Win10 64-bit Enterprise |
