IB818

Ordinateur monocarte 3,5 po — Intel® Atom® x7/x5/ Pentium®/ Celeron® SoC

Ordinateur monocarte 3,5 po — Intel® Atom® x7/x5/ Pentium®/ Celeron® SoC. Distribué au Canada et aux États-Unis par IBT Technologies, revendeur autorisé IBASE, avec soutien de garantie local et personnalisation d’ingénierie offerte sur demande.

CPU

Intel Atom® x7-E3950 Processor (1.6GHz~2.0GHz)Intel Atom® x5-E3940 Processor (1.6 GHz~1.8GHz)Intel Atom® x5-E3930 Processor (1.3 GHz~1.8GHz)Intel® Pentium® Processor N4200 (1.1GHz~ 2.5GHz)Intel® Celeron® Processor N3350 (1.1GHz~ 2.4GHz)Intel® Celeron® Processor J3455(1.5GHz~ 2.3GHz)

MEMORY

1x DDR3L SO-DIMM, Max 8GB (Non-ECC)

STORAGE

1x mSATA (via full-size Mini PCI-E)

DISPLAY

Supports HDMI(1.4b), Dual LVDS (18/24bit)

x86 based 3.5 Single Board…Single Board Computer

DEMANDER UNE SOUMISSION FICHE TECHNIQUE (PDF)

N° DE PIÈCE FABRICANT IB818 — IBASE Technology · VOIR LA PAGE DU FABRICANT ↗

Specifications

24 LIGNES

CPU	Intel Atom® x7-E3950 Processor (1.6GHz~2.0GHz)Intel Atom® x5-E3940 Processor (1.6 GHz~1.8GHz)Intel Atom® x5-E3930 Processor (1.3 GHz~1.8GHz)Intel® Pentium® Processor N4200 (1.1GHz~ 2.5GHz)Intel® Celeron® Processor N3350 (1.1GHz~ 2.4GHz)Intel® Celeron® Processor J3455(1.5GHz~ 2.3GHz)
PCH	Integrated in Intel® SoC
Memory	1x DDR3L SO-DIMM, Max 8GB (Non-ECC)
BIOS	AMI
Watchdog Timer	256 levels
H/W Monitor	Yes
Storage Device Interface	1x mSATA (via full-size Mini PCI-E)
Mini Type Slots	2x Mini PCI-E (1x full-size, 1x half-size)
Graphics Controller	Intel® SoC integrated Gen9 18EUs graphics
Video Output	Supports HDMI(1.4b), Dual LVDS (18/24bit)
Ethernet	IB818F-I50 2x Intel® I210IT Gigabit LANIB818F-420/335: 2x Intel® I211AT or I210AT Gigabit LAN
I/O Chipset	Fintek F81964D-I
Serial Port	1x RS232/422/485 (jumper-less selection)3x RS232
USB 2.0	2x USB 2.0 via pin-header
USB 3.X	4x USB 3.0 on board
Serial ATA	2x SATA III
Audio	Intel® Atom® SoC built-in HD audio controller + Realtek ALC888S Codec w/ class-D speaker amplifier
TPM	TPM (2.0)
Others	Digital I/O, +12V~+24V DC-in, EuP/ErP
Dimensions (L x W)	102 x 147 mm (4" x 5.8")
Power Consumption	Intel® Atom® E3950, 1.6GHz w/ 8GB DDR3L+12V: 1.09AIntel Pentium N4200, 1.1GHz w/ 8GB DDR3L+12V: 1.09A
Operating Temperature	E3950/E3940/E3930: -40°C~85°C (-40°F~185°F)N4200/N3350: 0°C~+60°C (32°F~140°F)
Storage Temperature	-40°C~90°C (-40°F~194°F)
Relative Humidity	90% (non-condensing @60°C)
