IB884T
Intel Atom Z510PT Disk-size cpu card (RoHS
Intel Atom Z510PT Disk-size cpu card (RoHS. Local warranty support and engineering customization available on request.
CPU
BGA
DISPLAY
CRT+ 24-bit LVDS, Integrated · DDR2 SODimm Max 1 GB
ETHERNET
Intel 82574IT GbE LAN
OPERATING TEMP.
Support wide-temp.
P/N # IB884T
Specifications
10 ROWS
| CPU Socket | BGA |
|---|---|
| CPU type | Intel® Atom" Z510PT (1.1GHz) |
| Chipset | Intel® US15WPT onboard |
| Video Output | CRT+ 24-bit LVDS, Integrated · DDR2 SODimm Max 1 GB |
| Primary LAN | Intel 82574IT GbE LAN |
| Multi I/O | COM x 4 |
| Serial ATA | SATA x 2 |
| Form Factor | 3.5 Inch Disk-size |
| Power Source | DC-In(12V-19V) |
| Operating Temperature | Support wide-temp. |
I/O — Rear panel
Front access
Where the IB884T is deployed
USE CASE
OEM integration
Drop-in board for custom enclosures, instrumentation, and purpose-built hardware.
USE CASE
Industrial control
PLC-adjacent controllers, motion control, and machine-tending applications.
USE CASE
Embedded kiosks
Behind-display compute for purpose-built kiosk and terminal hardware.
USE CASE
Test & measurement
Instrument hosts and ATE controllers built around a serviceable long-lifecycle board.
Have a specific use case?
Our applications engineers will match your environment, software stack and I/O requirements to the right platform — or modify this one.
