| CPU | Intel® Atom™ D525 Processor · (1.8GHz, 1MB cache) |
| System Memory | 1x DDR3 SO-DIMM, Max. 4GB (Non-ECC) |
| System Chipset | Intel® 82801HBM I/O controller (ICH8M) |
| BIOS | AMI |
| Watchdog Timer | 256 levels |
| SSD | N/A |
| H/W Monitor | Yes |
| Expansion Slots | 1x Mini PCI-E |
| VGA Controller | Intel® Atom™ D525 Processor integrated GMA3150 graphics |
| VGA Memory | Max. shared memory – 224MB |
| Display Interface | Support CRT and 24-bit dual channel LVDS |
| LAN | 2x Realtek RTL-8111G-CG PCI-E Gigabit LAN 2x RJ-45 on board |
| I/O Chipset | Nuvoton NCT6627UD · 3x RS232 · 1x RS-232/422/485(jumperless selection), · 2x SATA II, 1x KB, 1x Mouse |
| USB | 2x ports on board · Pin headers for 6 ports (USB 2.0) |
| Audio | Intel® ICH8M built-in audio controller w/ Realtek ALC662-VD codec for 5.1CH |
| Others | Digital I/O, +12V DC In |
| Dimensions | 102mm x 147mm (4" x 5.8") |
| Max. Power Requirement | Intel® Atom™ D525 1.80 GHz · w/ 1x 2GB DDR3-1333 · 0.23 A · 2.38 A |
| Operating Temperature | 0°C~60°C (32°F~140°F) |
| Storage Temperature | -20°C~80°C (-4°F~176°F) |
| Relative Humidity | 90% (non-condensing @60°C) |
