IB96W

Ordinateur monocarte 3,5 po — 13th Gen Intel® Core™ Mobile Wide-Temp Processor

Ordinateur monocarte 3,5 po — 13th Gen Intel® Core™ Mobile Wide-Temp Processor. Distribué au Canada et aux États-Unis par IBT Technologies, revendeur autorisé IBASE, avec soutien de garantie local et personnalisation d’ingénierie offerte sur demande.

CPU

Onboard 13th Gen Intel® Core™ i7-1370PRE processor, support wide-temp

MEMORY

1x DDR5 SO-DIMM, Max.32GB, supports IBECC

STORAGE

M.2 (M2280 for NVMe) SATA III

DISPLAY

2x DisplayPort, eDP, and LVDS

x86 based 3.5 Single Board…Single Board Computer

DEMANDER UNE SOUMISSION FICHE TECHNIQUE (PDF)

N° DE PIÈCE FABRICANT IB96W — IBASE Technology · VOIR LA PAGE DU FABRICANT ↗

Specifications

24 LIGNES

CPU	Onboard 13th Gen Intel® Core™ i7-1370PRE processor, support wide-temp
PCH	N/A
Memory	1x DDR5 SO-DIMM, Max.32GB, supports IBECC
BIOS	AMI
Watchdog Timer	256 levels
H/W Monitor	Yes
Storage Device Interface	M.2 (M2280 for NVMe) SATA III
Mini Type Slots	1x M.2 (M-Key, Type:2280, with PCle (4x) signal only, supports NVMe)1x M.2 (E-Key, Type:2230, with PCle (1x) & USB 2.0 signal, supports CNVi)1x M.2 (B-Key, Type:3052, with PCle (1x) & USB 3.2 signal, supports 5G/LTE
Graphics Controller	13th Gen Intel® Core™ mobile processor integrated graphics
Video Output	2x DisplayPort, eDP, and LVDS
Ethernet	2x Intel® I226IT 2.5G LAN
I/O Chipset	Fintek F81804U-I
Serial Port	2x COM (RS232/422/485)
USB 2.0	3x USB 2.0 (1x Type-A ; 2x via pin headers)
USB 3.X	3x USB 3.2 (Type-A)
Serial ATA	2x SATA III
Audio	Integrated HD audio with ALC888S codec
TPM	fTPM only
Others	Digital I/O (4-in/4-out); +12V~+24V DC-in
Dimensions (L x W)	102mm x 147mm (4“ x 5.8“)
Power Consumption	Intel® Core™ i7-1370PRE processor, Up to 4.8GHz w/ 1x 32GB DDR5-5600 memory+24V: 3.82A
Operating Temperature	-40°C~+75°C (-40°F~+167°F)
Storage Temperature	-45°C~+80°C (-49°F~176°F)
Relative Humidity	10% ~ 90% (non-condensing)
