| CPU Socket | LGA1700 |
| CPU | 14th/13th/12th Gen Intel® Core™ i9/i7/i5/i3 processors |
| PCH | Intel® Q670E PCH |
| Memory | 2x DDR5-5600MHz DIMM, Max. 64GB, Non-ECC |
| BIOS | AMI |
| Watchdog Timer | 256 levels |
| H/W Monitor | Yes |
| Storage Device Interface | 1x M.2 (supports NVMe) |
| Expansion Slots | 4x PCI, 4x PCI-E (x1) or 1x PCI-E (x4)1x PCI-E (x16) from backplane |
| Mini Type Slots | 1x M.2 (M-Key, type:2280, supports NVMe)1x M.2 (E-Key, type:2230, supports CNVi) |
| Graphics Controller | Intel® DT processor integrated Xe graphics |
| Video Output | Supports DVI-I, DVI-D, 24-bit dual channel LVDS |
| Ethernet | Intel® I226LM 2.5G LANIntel® I226V 2.5G LAN (as 2nd LAN) |
| I/O Chip | Fintek F81966AB-I |
| Serial Port | 1x RS232/422/485 (jumperless selection), 3x RS232 |
| USB 2.0 | 1x USB 2.0 via M.2 (E-Key) |
| USB 3.X | 6x USB 3.2 on board1x USB 3.2 on edge IO1x USB 3.2 Type-A on board (vertical type) |
| Serial ATA | 5x SATA III |
| Audio | Intel® PCH built-in HD audio controller + Realtek ALC888S codec |
| TPM | dTPM (2.0) |
| Others | Printer port, Digital I/O (4-in/ 4-out), RAID, iAMT (16.1) |
| Dimensions (L x W) | 338mm x 126mm (13.3" x 4.96") |
| Power Consumption | Intel® Core™ i9-14900 Processor, Up to 5.80 GHzATLA AD5LHC16PBA1-CCAw/ 2x DDR5 5600 16GB+3.3V : 1.24A+5V : 0.35A+5VSB : 0.08A+12V : 23.45A |
| Operating Temperature | 0°C ~ 60°C(32°F ~ 140°F) |
| Storage Temperature | -20°C ~ 80°C(-4°F ~ 140°F) |
| Relative Humidity | 90%(non-condensing @60°C) |
