SI-334
DIGITAL SIGNAGE / IN STOCK

SI-334

AMD Ryzen™ Embedded V2000 Series Processor Signage Player with AMD Vega GPU and 4x HDMI

AMD Ryzen™ Embedded V2000 Series Processor Signage Player with AMD Vega GPU and 4x HDMI. Supplied across Canada and the United States by IBT Technologies, an authorized IBASE reseller, with local warranty support and engineering customization available on request.

CPU
AMD Ryzen™ Embedded V2000 Series Processors
MEMORY
2x DDR4-3200, SO-DIMM, dual channel, Max. 64GB
STORAGE
1x M.2 M-Key (2280)
ETHERNET
2x Realtek RTL8111H-CG Gigabit LAN controller
4 Display OutputsMid Range Signage Player
REQUEST QUOTE DATASHEET (PDF)
MFR. PART # SI-334 — IBASE Technology · VIEW MANUFACTURER PAGE ↗

Specifications

24 ROWS
System MainboardMBD334
CPUAMD Ryzen™ Embedded V2000 Series Processors
CPU SocketFP6 BGA package, 25mm x 35mm
ChipsetSoC integrated
Memory2x DDR4-3200, SO-DIMM, dual channel, Max. 64GB
GraphicsNext-gen AMD Vega GPU integrated
LAN2x Realtek RTL8111H-CG Gigabit LAN controller
Expansion Slots1x M.2 E-Key (2230)1x M.2 B-Key (3052)1x UIM/SIM card slot
I/O Interface4x HDMI 2.0 with hardware EDID emulation & CEC function4x USB 3.1 @Gen 2 (USB Type-A)2x RJ45 for Gigabit LAN1x RJ45 for RS-232 serial port1x Audio connector for Line-out1x Power button1x Power jack (+12V DC)2x Power/HDD LED
Auto Control and MonitoringWatchdog Timer: 256 segments, 0, 1, 2...255 (sec/min)
Power Requirement+12V DC-in
ConstructionAluminum + SGCC
Weight2.1 kgs (4.63 Ibs)
Chassis ColorBlack & white
Storage1x M.2 M-Key (2280)
Power Supply150W power adaptor
MountingSlim design with wall mounting holes
Dimensions269mm(W) x 193mm(D) x 31.5mm(H)10.59" (W) x 7.59" (D) x 1.24" (H)
Operating Temperature0°C~45°C (32°F~113°F)
Storage Temperature-20°C~80°C (-4°F~176°F)
Relative Humidity10%~90% (non-condensing)
VibrationM.2: 5 grms / 5~500Hz / random operation
CertificationCE, FCC Class A, UKCA, cULus, CCC
Operating SystemWin11 IoT Enterprise(64-bit)Win10 IoT Enterprise(64-bit)Linux Ubuntu(64-bit)
